Brand |
DOMA |
|---|---|
|
Manufacturer |
CHENGDU DOMA CARBIDE TOOLS CO.,LTD. |
|
Product Dimensions |
Standard or Customized |
|
Cutting Head Material |
Tungsten Carbide By Sinter-HIP |
|
Shank Material |
40Cr Steel |
|
Welding Method |
Silver-alloy Brazing |
|
Hot Selling Models |
H1025, H1232, SH-1, SH-5 |
|
OEM |
Available |
|
Free Sample |
Available |
1.The flame-shaped head is perfect for chamfering irregular weld seams, creating smooth transitions and removing sharp edges for better post-weld surface quality.
2.Ideal for large angle welds, providing smooth, seamless edge transitions and preventing sharp corners, ensuring better weld fit and appearance.
3.Efficiently removes weld marks, burrs, and protrusions, leaving a smooth base for subsequent welding processes, improving weld strength and aesthetics.
4.Offers stable, smooth cutting on materials like cast iron, steel, and stainless steel, with long-lasting durability for extended work cycles.
|
SH Type Flame Shape Carbide Rotary Burr |
|||||
|---|---|---|---|---|---|
|
Drawing |
Diagram of Application |
||||
|
|
|
||||
|
Metric Standard |
|||||
|
Shank Dia. (mm) |
Cutter Dia. (mm) |
Lgth. of Cut (mm) |
Overall Lgth. (mm) |
Tool No. |
The Combination of Head and Shank |
|
d2 |
d1 |
l2 |
l1 |
||
|
3 |
3 |
13 |
38 |
H0313 |
Solid |
|
5 |
13 |
51 |
H0513 |
Brazed |
|
|
6 |
13 |
51 |
H0613 |
Brazed |
|
|
6 |
6 |
18 |
63 |
H0618 |
Brazed |
|
8 |
20 |
65 |
H0820 |
Brazed |
|
|
10 |
25 |
70 |
H1025 |
Brazed |
|
|
12 |
32 |
77 |
H1232 |
Brazed |
|
|
16 |
36 |
81 |
H1636 |
Brazed |
|
|
19 |
41 |
86 |
H1941 |
Brazed |
|
|
8 |
12 |
32 |
77 |
H1232 |
Brazed |
|
16 |
36 |
81 |
H1636 |
Brazed |
|
|
19 |
41 |
86 |
H1941 |
Brazed |
|
|
Inch Standard |
|||||
|
Shank Dia. (inch) |
Cutter Dia. (inch) |
Lgth. of Cut (inch) |
Overall Lgth. (inch) |
Tool No. |
The Combination of Head and Shank |
|
d2 |
d1 |
l2 |
l1 |
||
|
1/8 |
1/8 |
1/4 |
1-1/2 |
SH-41 |
Solid |
|
1/4 |
1/4 |
5/7 |
2 |
SH-1 |
Solid |
|
5/16 |
3/4 |
2-1/2 |
SH-2 |
Brazed |
|
|
1/2 |
1-1/4 |
3 |
SH-5 |
Brazed |
|
|
5/8 |
1-7/16 |
3-1/5 |
*SH-6 |
Brazed |
|
|
3/4 |
1-5/8 |
3-3/8 |
*SH-7 |
Brazed |
|
Every DOMA rotary burr meets strict industrial standards. If any product fails under normal use, our support team will provide prompt replacement or technical assistance — your satisfaction is our priority.
