Place of Origin:	Sichuan, China		Brand:	DOMA
Model Number:	Customized		Material:	Tungsten Carbide Teeth
Gertificateade:	ISO9001:2008		Sample:	Available
OEM:	YES		Business Type:	Manufacturer

DOMA CARBIDE HOLE SAW TYPE SPECIFICATION LIST
Metric Size Standard
Specification (mm)	Inner Wall Depth (mm)	Total Length (mm)	Shank Diameter (mm)
16	20	88	9.8
18	20	88	9.8
18.5	20	88	9.8
19	20	88	9.8
20	20	88	9.8
20.5	20	88	9.8
22	20	88	9.8
22.5	20	88	9.8
25	20	88	9.8
25.5	20	88	9.8
30	20	88	9.8
32	20	88	9.8
35	20	88	9.8
40	20	88	9.8
42	20	88	9.8
45	20	88	9.8
50	20	88	9.8
55	20	88	9.8
60	20	88	9.8
65	20	88	9.8
70	20	88	9.8
75	20	88	12.8
80	20	88	12.8

♦ Doma carbide tools only show the commonly used hole saw specifications, if you want more other specification of hole saw, you are welcome to contact us. At the same time, Doma accepts drawing or sample customization.

---

♦ Application scope: Iron plate, stainless steel, aluminum plate, calcium silicate plate, plastic plate, resin plate, FRP plate.

♦ Effect: Our carbide teeth of the hole saw are made of ultra-fine particle tungsten carbide powder, which is still sharp after drilling many times, and the opening is smooth and without burrs.

♦ Advantage:

1.High-quality K10 tungsten carbide, raw material comes from Xiamen Tungsten(XTC), fine grinding technology.

2.The blade is inclined forward, and the design of the inclination angle of the tooth shape reduces the resistance and increases increases the perforation ability.

3.Triangular handle design, more stable and firm, and effectively prevent slipping during work.

♦ Match equipment: AC electric drille, bench drill.
