Brand |
DOMA |
---|---|
Manufacturer |
CHENGDU DOMA CARBIDE TOOLS CO.,LTD. |
Product Dimensions |
Standard or Customized |
Cutting Head Material |
Tungsten Carbide By Sinter-HIP |
Shank Material |
40Cr Steel |
Welding Method |
Silver-alloy Brazing |
Hot Selling Models |
B1020, B1225, SB-3, SB-5 |
OEM |
Available |
Free Sample |
Available |
CYLINDER WITH END CUT CARBIDE BURR |
|||||
---|---|---|---|---|---|
Drawing |
Diagram of Application |
||||
|
|
||||
Metric Standard |
|||||
Shank Dia. (mm) |
Cutter Dia. (mm) |
Lgth. of Cut (mm) |
Overall Lgth. (mm) |
Tool No. |
The Combination of Head and Shank |
d2 |
d1 |
l2 |
l1 |
||
3 |
1.5 |
6 |
38 |
B1506 |
Solid |
2 |
11 |
38 |
B0211 |
Solid |
|
2.5 |
12 |
38 |
B2512 |
Solid |
|
3 |
13 |
38 |
B0314 |
Solid |
|
4 |
13 |
51 |
B0413 |
Brazed |
|
5 |
13 |
51 |
B0513 |
Brazed |
|
6 |
13 |
51 |
B0513 |
Brazed |
|
6 |
6 |
16 |
51 |
B0618 |
Brazed |
6 |
25 |
50 |
B0625 |
Solid |
|
8 |
20 |
65 |
B0820 |
Brazed |
|
10 |
20 |
65 |
B1020 |
Brazed |
|
11 |
25 |
70 |
B1125 |
Brazed |
|
12 |
25 |
70 |
B1225 |
Brazed |
|
16 |
25 |
70 |
B1625 |
Brazed |
|
19 |
25 |
70 |
B1925 |
Brazed |
|
25 |
25 |
70 |
B2525 |
Brazed |
|
8 |
12 |
25 |
70 |
B1225 |
Brazed |
16 |
25 |
70 |
B1625 |
Brazed |
|
19 |
25 |
70 |
B1925 |
Brazed |
|
25 |
25 |
70 |
B2525 |
Brazed |
|
Inch Standard |
|||||
Shank Dia. (inch) |
Cutter Dia. (inch) |
Lgth. of Cut (inch) |
Overall Lgth. (inch) |
Tool No. |
The Combination of Head and Shank |
d2 |
d1 |
l2 |
l1 |
||
3/8 |
7/8 |
1 |
2-3/4 |
*SB-8 |
Brazed |
1/8 |
1/16 |
1/4 |
1-1/2 |
SB-41 |
Solid |
1/8 |
9/16 |
1-1/2 |
SB-43 |
Solid |
|
1/4 |
5/32 |
5/8 |
2 |
SB-13 |
Solid |
3/16 |
5/8 |
2 |
SB-14 |
Solid |
|
1/4 |
5/8 |
2 |
SB-1 |
Solid |
|
1/4 |
1 |
2 |
SB-1L |
Solid |
|
5/16 |
3/4 |
2-1/2 |
SB-2 |
Brazed |
|
3/8 |
3/4 |
2-1/2 |
SB-3 |
Brazed |
|
7/16 |
1 |
2-3/4 |
SB-4 |
Brazed |
|
1/2 |
1 |
2-3/4 |
SB-5 |
Brazed |
|
5/8 |
1 |
2-3/4 |
*SB-6 |
Brazed |
|
3/4 |
1 |
2-3/4 |
*SB-7 |
Brazed |
|
1 |
1 |
2-3/4 |
*SB-9 |
Brazed |
* If the carbide burr made by us breaks in normal use, we will double the compensation.
