Ball Nose Tree Carbide Burr

Item No.: F
Ball nose tree carbide burr made by Doma carbide tools are of first-class quality, they are suitable for grinding the arc profile of the workpieces where in narrow space.
Description


Outline




  Brand

  DOMA

  Manufacturer

  CHENGDU DOMA CARBIDE TOOLS CO.,LTD.

  Product Dimensions

  Standard or Customized

  Cutting Head Material

  Tungsten Carbide By Sinter-HIP

  Shank Material

  40Cr Steel

  Welding Method

  Silver-alloy Brazing

  Hot Selling Models

  F1020, F1225, SF-3, SF-5

  OEM

  Available

  Free Sample

  Available


Specification




BALL NOSE TREE CARBIDE BURR

Drawing

Diagram of Application

carbide burr size F.jpg

carbide burr F.jpg

Metric Standard

Shank Dia. (mm)

Cutter Dia. (mm)

Lgth. of Cut (mm)

Overall Lgth. (mm)

Tool No.

The Combination of Head and Shank

d2

d1

l2

l1

3

3

13

38

F0313

Solid

5

13

51

F0513

Brazed

6

13

51

F0613

Brazed

6

6

18

63

F0618

Brazed

8

20

65

F0820

Brazed

10

20

65

F1020

Brazed

11

25

70

F1125

Brazed

12

25

70

F1225

Brazed

16

25

70

F1625

Brazed

19

25

70

F1925

Brazed

8

12

25

70

F1225

Brazed

16

25

70

F1625

Brazed

19

25

70

F1925

Brazed

Inch Standard

Shank Dia. (inch)

Cutter Dia. (inch)

Lgth. of Cut (inch)

Overall Lgth. (inch)

Tool No.

The Combination of Head and Shank

d2

d1

l2

l1

1/8

1/8

1/2

1-1/2

SF-42

Solid

1/4

1/2

2

SF-51

Brazed

1/4

3/8

3/4

2-1/2

SF-3

Brazed

7/16

1

2-3/4

SF-4

Brazed

1/2

3/4

2-1/2

SF-13

Brazed

1/2

1

2-3/4

SF-5

Brazed

5/8

1

2-3/4

*SF-6

Brazed

3/4

1

2-3/4

*SF-7

Brazed

3/4

1-1/4

3

*SF-14

Brazed

3/8

3/4

1-1/4

3-1/4

*SF-15

Brazed


Promise




* If the carbide burr made by us breaks in normal use, we will double the compensation.
