Brand |
DOMA |
|---|---|
|
Manufacturer |
CHENGDU DOMA CARBIDE TOOLS CO.,LTD. |
|
Product Dimensions |
Standard or Customized |
|
Cutting Head Material |
Tungsten Carbide By Sinter-HIP |
|
Shank Material |
40Cr Steel |
|
Welding Method |
Silver-alloy Brazing |
|
Hot Selling Models |
L1025, L1228, SL-3, SL-4 |
|
OEM |
Available |
|
Free Sample |
Available |
1.The long tapered cone shape with a ball nose is perfect for precise grinding of U-shaped grooves and contouring uneven surfaces.
2.Ideal for working on deep, uneven grooves, allowing precise control over the cutting depth.
3.Efficiently removes weld burrs and protrusions, making it ideal for weld seam finishing.
4.Provides fast and stable cutting, suitable for metal surface finishing on materials like cast iron, steel, and stainless steel.
|
SL Type Ball Nose Cone Carbide Rotary Burr |
||||||
|---|---|---|---|---|---|---|
|
Drawing |
Diagram of Application |
|||||
|
|
|
|||||
|
Metric Standard |
||||||
|
Shank Dia. (mm) |
Cutter Dia. (mm) |
Lgth. of Cut (mm) |
Overall Lgth. (mm) |
Included Angle |
Tool No. |
The Combination of Head and Shank |
|
d2 |
d1 |
l2 |
l1 |
|||
|
3 |
3 |
13 |
38 |
8° |
L0313 |
Solid |
|
5 |
13 |
38 |
10° |
L0513 |
Brazed |
|
|
6 |
13 |
48 |
10° |
L0613 |
Brazed |
|
|
6 |
6 |
16 |
51 |
14° |
L0616 |
Brazed |
|
8 |
22 |
70 |
14° |
L08254 |
Brazed |
|
|
10 |
25 |
70 |
14° |
L1025 |
Brazed |
|
|
12 |
28 |
73 |
14° |
L1228 |
Brazed |
|
|
16 |
33 |
78 |
14° |
L1633 |
Brazed |
|
|
19 |
38 |
83 |
14° |
L1938 |
Brazed |
|
|
8 |
12 |
28 |
73 |
14° |
L1228 |
Brazed |
|
16 |
33 |
78 |
14° |
L1633 |
Brazed |
|
|
19 |
38 |
83 |
14° |
L1938 |
Brazed |
|
|
Inch Standard |
||||||
|
Shank Dia. (inch) |
Cutter Dia. (inch) |
Lgth. of Cut (inch) |
Overall Lgth. (inch) |
Included Angle |
Tool No. |
The Combination of Head and Shank |
|
d2 |
d1 |
l2 |
l1 |
|||
|
1/8 |
1/8 |
1/2 |
1-1/2 |
8° |
SL-42 |
Solid |
|
1/4 |
1/4 |
5/8 |
2 |
14° |
SL-1 |
Brazed |
|
5/16 |
7/8 |
2-3/4 |
14° |
SL-2 |
Brazed |
|
|
3/8 |
1-1/16 |
2-15/16 |
14° |
SL-3 |
Brazed |
|
|
1/2 |
1-1/8 |
73.575MM |
14° |
SL-4 |
Brazed |
|
|
1/2 |
1-1/4 |
76.75MM |
14° |
|
Brazed |
|
|
5/8 |
1-5/16 |
3-1/16 |
14° |
*SL-5 |
Brazed |
|
|
5/8 |
1-7/16 |
3-1/5 |
14° |
*SL-6 |
Brazed |
|
|
3/4 |
1-5/8 |
3-3/8 |
14° |
*SL-7 |
Brazed |
|
Every DOMA rotary burr meets strict industrial standards. If any product fails under normal use, our support team will provide prompt replacement or technical assistance — your satisfaction is our priority.
For detailed material specifications, cutting head types, and maintenance tips, please visit our [Carbide Burr Overview]
